Electro-Voice ZLX-15-G2

Technical Specifications

• Frequency response (-3 dB) (Hz): 68 Hz – 18,000 Hz
• Frequency range (-10 dB) (Hz): 53 Hz – 20,000 Hz
• Axial sensitivity (dB SPL 1W/1m): 95 dB SPL 1W/1m
• Maximum sound pressure level at a distance of 1 m (dB): 126 dB
• High pass frequency (Hz): 40 Hz
• Crossover frequency (kHz): 2 kHz
• Coverage angle HxV (°): 90° x 60°
• Power handling (continuous) (W): 250 W
• Power handling (peak) (W): 1,000 W
• Nominal impedance (Ω): 8Ω
• LF transducer: WECA2158
• LF transducer size (in): 15 in
• LF transducer magnet material: Ferrite
• HF transducer: DH-1K
• HF transducer type: Compression driver
• HF transducer size (in): 1.4 in
• HF transducer diaphragm material: Titanium
• Dimensions (H x W x D) (mm): 697.6 mm x 422.8 mm x 383.1 mm
• Dimensions (H x W x D) (in): 27.46 in x 16.65 in x 15.08 in
